It is equipped with mature three-electric system (battery, motor and electric control system) for mining vehicles. With main assembly strengthening design, it is more suitable for mining conditions. The vehicle has low center of gravity, strong bearing capacity as well as bending and torsional resistance.
It is equipped with mature three-electric system (battery, motor and electric control system) for mining vehicles. With main assembly strengthening design, it is more suitable for mining conditions. The vehicle has low center of gravity, strong bearing capacity as well as bending and torsional resistance.
The vehicle adopts high speed ratio axle, with maximum gradient of 30%. The motor has reached the rated torque at low speed, with short vehicle acceleration time and fast speeding up.
It features long repair and maintenance cycle of core components, stable and reliable three-electric system (battery, motor and electric control system), and high vehicle attendance; it is also characterized by large tank volume, fast average speed and high single transport efficiency, bringing greater operating income.
The vehicle uses full-floating rear suspension and semi-floating front suspension, alleviating driver fatigue. The pneumatic suspension structure can effectively absorb road impact and improve driving comfort.
| Vehicle parameter | |
|---|---|
| Length x Width x Height (mm) | 9400×3750×4000 |
| Wheelbase (mm) | 4000+1750 |
| Maximum gradient | ≥ 30 |
| Curb weight (kg) | 38000 |
| Maximum total mass (kg) | 95000 |
| Maximum speed (km/h) | 40 |
| Upperstructure configuration | |
|---|---|
| Lifting system | Single cylinder front lifting system |
| Container volume (m³) | 36 (flat loading)/39 (stowage loading) |
| Chassis configuration | |
|---|---|
| Steering system | Full hydraulic pressure steering + emergency steering, centralized lubrication (optional) |
| Tire | 16.00R25 three-star rating (Techking). Other brands of tires are available. |
| Power battery (kWh) | CATL, lithium iron phosphate 396kWh/528kWh (optional) |
| Drive motor | Disc hub dual-motor/Lego (optional) |
| Transmission | FAST four-speed AMT mining truck special/Qijiang two-speed transmission |
| Front middle and rear axle load (t) | 25+35+35 |
| Suspension system | Front hydro-pneumatic spring suspension/rear leaf spring balance suspension |
| Brake system | Electric brake + drum brake, eddy current retarder (optional) |
| Motor rated/peak power (kW) | Disk hub: 450/800; Lego: 500/800 |
